DSCA34, RTD Input Analog Signal Conditioner DIN Rail Modules
The DSCA34 input module provides a single channel of RTD input which is filtered, isolated, amplified, linearized and converted to a high-level analog output. The module has excellent stability over time and do not require recalibration.
Features:
- Linearized 2- or 3-Wire RTD Input Module
- 1500 V Transformer Isolation
- True 3-Way Isolation
- Accuracy: ± 0.08%
- DIN Rail Mounted Module
- ANSI/IEEE C37.90.1 Transient Protection
- Input Protected to 240 V AC Continuous
Manufacturer: Dataforth
Quote
Datasheet
Specifications
Models & Accessories
Downloads
Similar Products
DSCA34 - Specifications
| Input Type | RTD |
| # of Inputs | 1 |
| Output Type | 0 - 10 V DC |
| 0 - 20 mA | |
| 4 - 20 mA | |
| Max Bandwidth | 3 Hz |
| Isolation | Yes |
| Supply Power | 15 - 30 V DC |
