MAQ20-MV, Millivolt Input Module
The MAQ20-MV millivolt analog input modules interface to a wide range of millivolt sensors and equipment used in industrial and test and measurement applications. All channels are individually configurable for range, alarm limits and averaging.
Features:
- 8 Millivolt Input Channels
- Differential Inputs
- Configurable Channels
- Input-to-Bus Isolation, 1500 Vrms
- Channel Overload Protection, 240 Vrms
- Selective Enabling of Channels for Scanning
Manufacturer: Dataforth
Quote
Datasheet
Specifications
Applications
Downloads
Similar Products
MAQ20-MV - Specifications
| Family | Dataforth MAQ20 |
| Unit Type | Module |
| Input Type | Voltage |
| Analog Inputs | 8 |
| Min Temperature | -40 °C |
| Max Temperature | 85 °C |
MAQ20-MV - Applications
The number of applications for these modules is extensive. A wide range of Process parameters and variables can be accommodated because of the level of isolation.
If there are multiple sources with different power sources with different isolation levels, then multiple modules can be used, or the 5B and 8B modules can be used.
