MAQ20-BRDG1, Bridge Input Module
The MAQ20 input module has channels that are individually configurable for range, and engineering values, to match the most demanding applications. Sampling rate, resolution, bandwidth, excitation voltage and shunt calibration are user...
Features:
- 4 Bridge/Strain Gauge Input Channels
- Supports Quarter Half & Full Bridge configurations
- 4 or 6-wire Sensor Inputs for excitation drop compensation
- Input-to-Bus Isolation, 1500 Vrms
- Channel Overload Protection, 30 Vrms
- Individually Configurable Inputs
- Simultaneous Sampling using dedicated A/D convertors
- Burst Mode
- Programmable Bandwidth, Excitation, Shunt Calibration
- Programmable Sampling Rate & Resolution
Manufacturer: Dataforth
Quote
Datasheet
Description
Specifications
Applications
Downloads
Related Products
Similar Products
MAQ20-BRDG1 - Description
The MAQ20 input module has channels that are individually configurable for range, and engineering values, to match the most demanding applications. Sampling rate, resolution, bandwidth, excitation voltage and shunt calibration are user selectable.
Multiple Bridge modules can be added to expand the systems channel capacity.
MAQ20-BRDG1 - Specifications
| Family | Dataforth MAQ20 |
| Unit Type | Module |
| Input Type | Strain Gauge |
| Analog Inputs | 4 |
| Min Temperature | -40 °C |
| Max Temperature | 85 °C |
MAQ20-BRDG1 - Applications
Applications include Structural Testing, Materials Testing, Weighing, Process Monitoring, etc.
These can be used in Field Installations, Continuous Processes and Lab Testing. They are very economical for small or large channel counts, and are easily expanded, making them excellent for Student Labs and Educational facilities.
