MAQ20-DIOH, Discrete I/O Module
MAQ20-DIOH discrete input/output module has 4 isolated discrete inputs and 4 discrete isolated outputs. Input channels accept 90-280 VAC/VDC signals and output channels switch 24-280 VAC signals at up to 3A AC load.
Features:
- 4 Discrete Voltage Input Channels
- 4 Discrete Voltage Output Channels
- Input-to-Bus Isolation, 1500 Vrms
- Channel-to-Channel Isolation, 300 Vrms
- Overload & Reverse Protection
- Industrial Control
- User-Defined Default & Waveform Output
- 7 High Performance Special Functions
Manufacturer: Dataforth
Quote
Datasheet
Specifications
Downloads
Similar Products
MAQ20-DIOH - Specifications
| Family | Dataforth MAQ20 |
| Unit Type | Module |
| Input Type | Voltage |
| Frequency | |
| Analog Inputs | 4 |
| Analog Outputs | 4 |
| Min Temperature | -40 °C |
| Max Temperature | 85 °C |
