MPS 500, Compact and Modular Leak Test Panel
- Single channel measuring system
- Pressure decay/rise method
- Relative or differential pressure
- Mass flow rate/ volume flow measurement
- Electronic proportional pressure regulator
- 32 test programs
- 7" TFT colour monitor with touchscreen
- up to 100,000 measurements
- Binary I/O,
- 2 × USB
- Optional Profibus, Profinet and Ethernet IP
- 24 VDC, 2.5 A
- approx. 295 × 150 × 390 mm
- approx. 8 kg
- RAL 7021 black grey
The MPS 500 is a proven workhorse, operating on Pressure Decay Principle for leak testing. The Electronic Pressure Regulation ensures accurate test pressure control, while the high accuracy flow sensor decreases test time and minimizes errors. The MPS 400 is available for both internal pressure test, as well as negative pressure vacuum tests.
Internally the no-leak valves ensure that system leak does not skew results. Temperature Compensation allows for testing even in the face of varying temperatures.
The ability for the MPS 500 to control JWF external valves allows us to provide complete systems with Cavity Selection and Automatic Leak Mastering capabilities.
The 7" Touchscreen allows for full data and curve visualization, with ability to customize for different test sequences.
Full networking capabilities allow for storage to servers and databases such as QDAS and QualityWorks, with interfaces already provided for simple integration. Fieldbus such as Ethernet IP, Profinet, and Profibus are available.
The MPS 500 is capable and versatile, contact us so we can get started detailing a solution for your leak testing application.
