ForTest - T9730, Continuous Measurement High performance flow Tester
![T9730, Continuous Measurement High performance flow Tester](img/series/T9730_image.png)
![T9730, Continuous Measurement High performance flow Tester](img/series/T9730_image.png)
- Multiple Programs for various applications
- HMI touchscreen controller
- Multiple Languages, English, French, Spanish, Italian, …
- Sequence – Fill to Test Pressure, Stabilize, Measure Absolute Pressure Decay, calibrated leak rate
- Data Collection by Serial Number, using a PC or PLC (optional Field buses, Ethernet IP, Modbus)
Thanks to use of technology based on the “Coriolis” effect, the T9730 is among the leaders of flow leak testing in terms of precision and linearity of the measurement.
This particular technology was designed to guarantee high performance, short response time and high level of immunity to noise, and is exclusive to the ForTest T9000 series.
Other than the classic flow measurement, the tool also has other ways of making it as versatile as possible in its category: ascent and descent ramps, opening tests and burst testing.
Another separate function is the "continuous measurement", i.e. a test with infinite times allowing adjustment of the taps and part repairs in real time.
One of the tools advantage is that of intelligent pressure adjustment, which uses the automatic pressure regulator to continuously adjust the test pressure based on the variation in load loss, to ensure the reading is as stable and repetitive as possible.
Advanced interface.
Fortest considers the T9000 series as the most technologically forward of measurement systems, equipped with an advanced interface, useful for analysis and research during the prototyping or pre-series phase, as well as for production line testing.
The big, 7” colour display set in a capacitive glass panel allows total interaction with the internal menus and the main screen. The "smart" testing archive contains daily and monthly analysis functions and those specifically for each test program, to keep the level of quality of your products under control.
Limitless connectivity.
The new T9730 equipment includes ports for the USB slave, RS232, RS485, Can bus and TTY. Assembly may also include an optional Ethernet port and a 26-pole connector with 4 inputs and 8 outputs, which are completely programmable, for interfacing with the external valves, safety barriers, switches, etc...
The front panel has a master USB port assembled on it for connection to a USB key to save the tests conducted, backup/restore parameters and upgrade tool firmware. The connection to thermal printers, barcode/data-matrix readers and markers takes place automatically using an internal menu.
Top category technology.
Fortest decided not to make compromises when equipping the T9730, assembling the best components currently on the market, such as the piezoelectric electronic regulator which guarantees stable and repetitive adjustment, or the "Coriolis" sensor, which is incredibly accurate. Neither have they done it with the solid-state sensor with a vast reading range, or the specific valves for this model, which has a life estimated in the tens of millions of cycles.
All these advantages give never before seen precision performance, stability and accuracy.
Measurement resolution starts at 1 cc / min based on the scale end, ranging from 20 to 200 l / min, with maximum pressures of 2 bar
Made to measure pneumatic section.
To avoid overheating due to long activation times of the filling circuit, we have designed particular, high capacity pneumatic valves. They not only work in hot temperatures, but also quickly fill the piece being tested, making the T9730 also suitable for testing on parts with significant volumes.
All of the above, while maintaining ForTest's historic reliability.
Technical Specifications
• Dimensions 300x160x350 mm
• Weight 10 Kg
• Electrical Supply 24VDC, 110 VAC, 230 VAC
• Air tube size: 4x2.7, 6x4, 8x6, 10x8
Type | Mass Flow |
# of Channels | 1 |
Resolution | 0.01 sccm/min |
Display | 7" Colour Display |
Data Storage | USB |
Interface | RS-232 |
RS-485 | |
Profinet | |
EtherCAT | |
Ethernet TCP/IP | |
Accuracy | 0.5% |
Aerospace, Automotive, Household Appliances, Valves, Medical, Packaging and many more
External exhaust solenoid with protection filter | |
External start button | |
External start/abort pushbutton | |
External pushbutton 4 programs selection | |
Start pedal | |
Barcode reader | |
Adhesive label for printer 4500pcs | |
Aux signals extension cable | |
Air filter | |
Staubli male connector | |
Precision micrometer nozzle | |
Micrometer nozzle | |
M series manager software | |
TTY | |
Serial protocol | |
PC serial cable owner - M Series | |
External temperature probe | |
MIXER-07 | |
Software Data Manager | |
Staubli female fitting | |
Thermal printer with peel-off | |
Thermal printer without peel | |
Adapter cable AUX M Series - ET Series | |
Remote Start / Abort / Good / Reject | |
Air filter 5 micron | |
Pneumatic filling fast - (STANDARD) | |
Frontal connector for Staubli calibrated leak | |
Frontal precision pressure regulator | |
Electronic pressure Regulator | |
Auto zero primary pressure circuit | |
Pre-Filling | |
Waiting Primary pressure reading | |
Secondary Output of Waste (third result) | |
Leak Analog Output | |
I/O 24 Vdc expansion signal card | |
Bi-manual logic Start Input | |
Ethernet plug/TCP-IP | |
Active USB port | |
WI-FI connection | |
Radio remote control selection Kit | |
High resolution measure - (STANDARD) |
