MV-ID6120PM-00C-NNG, 12 MP, Smart Code Reader
With built-in code reading algorithm, MV-ID6120PM-00C-NNG smart code reader can read different types of 1-dimensional code and 2-dimensional code with reading speed up to 84 codes/sec.
Features:
- Adopts 12 MP sensor to provide high-quality images.
- Flexible installation and convenient debugging.
- Supports continuous reading of various codes without stopping.
- Supports recognizing various poor printing quality codes.
- Supports networking of multiple devices.
- Ingress protection 67.
Manufacturer: HIKROBOT
Quote
Datasheet
Description
Specifications
Applications
Downloads
Similar Products
MV-ID6120PM-00C-NNG, 12 MP - Description
With built-in code reading algorithm, MV-ID6120PM-00C-NNG smart code reader can read different types of 1-dimensional code and 2-dimensional code with reading speed up to 84 codes/sec. It adopts deep learning algorithm to process images with good robustness, and can recognize various poor printing quality codes.
MV-ID6120PM-00C-NNG, 12 MP - Specifications
| Resolution | 12 MP |
| Power Supply | 12 VDC |
| 24 VDC | |
| Max Reading Speed | 84 codes/sec |
| Data Interface | Gigabit Ethernet |
| Communication | FTP |
| HTTP | |
| Serial | |
| SmartSDK | |
| TCP Client/Server | |
| 1-Dimensional Code | Code 11 |
| Code 39 | |
| Code 93 | |
| Code 128 | |
| CodaBar | |
| ITF 25 | |
| 2-Dimensional Code | Data Matrix |
| QR Code |
MV-ID6120PM-00C-NNG, 12 MP - Applications
Express delivery and logistics, airport, e-commerce warehouse, etc.
MV-ID6120PM-00C-NNG, 12 MP - Downloads
MV-ID6120PM-00C-NNG Datasheet |
