APCI-3300, Pressure Measurement Board for PCI
The APCI-3300 pressure measurement board features optical isolation, creeping distance, overvoltage protection and protection against high-frequency EMI.
Features:
- Pressure Measurement Board for PCI
- PCI 3.3 V or PCI 5 V
- Up to 8 Channels for Strain Gauges
- Up to 8 Onboard Voltage Sources
- 18-bit Resolution
- Optical Isolation 1000 V
- Software Linearization
- Direct Connection of Pressure Sensor to PX3200-G Screw Terminal Panel
Manufacturer: ADDI-DATA GmbH
Quote
Datasheet
Specifications
Models & Accessories
Downloads
Similar Products
APCI-3300 - Specifications
| Borad Type | PCI |
| Input Type | Voltage |
| Strain Gauge | |
| Digital | |
| Analog Inputs | 4 |
| 8 | |
| Digital Inputs | 4 |
| Digital Outputs | 3 |
APCI-3300 - Models & Accessories
Models
| APCI-3300-8 | 8 Analog Inputs for Pressure Signals |
| APCI-3300-4 | 4 Analog Inputs for Pressure Signals |
APCI-3300 - Downloads
APCI-3300 Pressure Measurement Board for PCI Datasheet |
