MAQ20-RTD41, RTD Input Module
The MAQ20-RTD41 input module interfaces to 4-wire sensors and has 5 input channels. All channels are individually configurable for sensor, range, alarms and averaging to match the most demanding applications. Various Software Interfaces are...
Features:
- 5 Analog Input Channels
- 4-Wire RTD (Pt100, Ni120) or Potentiometer Inputs
- Input-to-Bus Isolation, 1500 Vrms
- Overload Protection up to 240 Vrms
- Configurable Channels
- Selective Enabling of Channels for Scanning
Manufacturer: Dataforth
Quote
Datasheet
Description
Specifications
Applications
Downloads
Similar Products
MAQ20-RTD41 - Description
The MAQ20-RTD41 input module interfaces to 4-wire sensors and has 5 input channels. All channels are individually configurable for sensor, range, alarms and averaging to match the most demanding applications.
Various Software Interfaces are available for configuration, Graphical Presentation (GUI / HMI), Control, Data Analysis and Reporting.
MAQ20-RTD41 - Specifications
| Family | Dataforth MAQ20 |
| Unit Type | Module |
| Input Type | Thermocouple/RTD |
| Analog Inputs | 5 |
| Min Temperature | -40 °C |
| Max Temperature | 85 °C |
MAQ20-RTD41 - Applications
There are many applications for these modules, monitoring various Processes, Thermal, Mill, etc. These can also be used to monitor Environmental conditions.
For Quality Control, these can be used for Process Verification, Data Collection, Reporting, etc.
